Thermal Insulation

Thermal Insulation

BAMBOO CHARCOAL THERMAL INSULATION

Brand new material for heat preservation - bamboo charcoal thermal isolating fiber. Taiwan Paiho worked with the Material Research Laboratories, ITRI to develop a light and thin thermal insulation “BamCoalTex”. The material’s rate of moisture content is less than 1% and retains its thermal effect even when it is wet.


how it's made

  • Bamboo charcoal submicrometer process and technology of blending is environmental-friendly.
  • Unique porous structure can absorb body's temperature and reflect it to the skin to have the body feel warm.
  • BamCoalTex thermal insulation is manufacturing in environmental consciousness, excluding gum, use low melting point polyester, shape changeless after wash.
  • BamCoalTex thermal insulation use a specialist interweaving technology, will never feel stifling for long term wearing.

KEEP WARM EFFICIENTLY

  • When a certain amount of air is retained between your body and warm clothes, the temperature of the air will gradually rise even when the exterior environment is bitterly cold.
  • BamCoalTex helps to keep our body warm by conserving our body heat in the spaces of numerous charcoal particles on the fiber.


hollow staple fiber

  • Sub-micron bamboo charcoal particles are added to polyester to absorb body heat into their superfine pores.
  • The thermal effect is superior to that of feather and man-made fiber of all kinds.
  • Wash-resistant, free from deformation, light and fine texture.
  • BamCoalTex’ s hollow staple fiber can enhance thermal effect by 10%–15%.

TYPE Y

  • JCYP 160 g/m2
  • Width: 60"
  • Feature: Fluffy, Softness and Durable.
  • Composition: 100% Polyester (Bamboo Charcoal Fiber)
  • Thermal Resistance (CLO): 2.35 (test standard: ASTM 1518-1985)
  • The warmth keeping ability rating (%): 80.4% (standard: JIS L1096)
  • The test result was tested by SGS laboratory, test condition: 21°C, RH66%

TYPE Q

  • JCQP 140 g/m2
  • Width: 60"
  • Feature: Fluffy, Softness and Durable.
  • Composition: 100% Polyester (Bamboo Charcoal Fiber)
  • Thermal Resistance (CLO): 2.46 (test standard: ASTM 1518-1985)
  • The warmth keeping ability rating (%): 81.5% (standard: JIS L1096)
  • The test result was tested by SGS laboratory, test condition: 21°C, RH66%

TYPE S

  • JCSP 150 g/m2
  • Width: 60"
  • Feature: Fluffy, Softness and Durable.
  • Composition: 100% Polyester (Bamboo Charcoal Fiber)
  • Thermal Resistance (CLO): 1.34 (test standard: ASTM 1518-1985)
  • The warmth keeping ability rating (%): 69.6% (standard: JIS L1096)
  • The test result was tested by SGS laboratory, test condition: 21°C, RH66%


APPLICATION

TYPE Y

Apparel, snow jackets, jackets and coats

TYPE Q

Gloves, shoes and shoe pads

TYPE S

Sleeping bags and bedding
